| Specification | Details |
|---|---|
| Brand | MSI |
| Model | B850M GAMING WIFI |
| Product Type | Gaming Motherboard |
| Chipset | AMD B850 |
| CPU Socket | AMD AM5 |
| CPU Support | AMD Ryzen 9000 / 8000 / 7000 Series |
| Memory Type | DDR5 |
| Memory Slots | 2 × DDR5 UDIMM |
| Maximum Memory | 128GB |
| Memory Speed | DDR5 8200–5600 MT/s (OC) / 5600–4800 MT/s (JEDEC) |
| Memory Support | Dual Channel / AMD EXPO / Non-ECC / Unbuffered |
| PCIe Slots | 1 × PCIe 5.0 x16 / 1 × PCIe 4.0 x4 |
| M.2 Slots | 1 × PCIe 5.0 x4 / 1 × PCIe 4.0 x4 |
| SATA | 4 × SATA 6Gbps |
| RAID | SATA RAID 0/1/10; M.2 RAID 0/1 |
| LAN | Realtek 8126 5G LAN |
| Wi-Fi | Wi-Fi 7 |
| Bluetooth | Bluetooth 5.4 |
| HDMI | 1 × HDMI 2.1, up to 4K 60Hz |
| DisplayPort | 1 × DisplayPort 1.4, up to 4K 60Hz |
| USB Rear | 2 × USB 2.0, 3 × USB 5Gbps Type-A, 1 × USB 5Gbps Type-C |
| USB Front | 4 × USB 2.0, 2 × USB 5Gbps Type-A, 1 × USB 10Gbps Type-C |
| Audio | Realtek ALC897, 7.1-Channel HD Audio |
| RGB | 3 × Addressable V2 RGB + 1 × RGB LED |
| TPM | TPM 2.0 Header |
| Debug LED | EZ Debug LED |
| Operating System | Windows 11 64-bit |
| Form Factor | Micro-ATX |
| Dimensions | 226 × 243.84mm |
